THK-THKS High stability horizontal plate clamp 500 to 3000 kg

This plate clamp is very stable. It can carry loads from 500 kg to 3 tons (9 models are available) in vertical position. It requires the use of an appropriate sling.

€33.00 - €90.00

Svuota
CATALOGUE
Contatto
Confronto
Aggiungi alla lista dei desideri
COD: THK-THKS Categoria:
Designation
THK10 - High stability horizontal plate clamp 1000 kg - 100 mm max. openingTHK10
High stability horizontal plate clamp 1000 kg – 100 mm max. opening

Weight : 7 kg
Bar code : 3700664802329
Catalogue P.253
THK15 - High stability horizontal plate clamp 1500 kg - 100 mm max. openingTHK15
High stability horizontal plate clamp 1500 kg – 100 mm max. opening

Weight : 7.5 kg
Bar code : 3700664802343
Catalogue P.253
THK20 - High stability horizontal plate clamp 2000 kg - 100 mm max. openingTHK20
High stability horizontal plate clamp 2000 kg – 100 mm max. opening

Weight : 9.5 kg
Bar code : 3700664802367
Catalogue P.253
THK30 - High stability horizontal plate clamp 3000 kg - 100 mm max. openingTHK30
High stability horizontal plate clamp 3000 kg – 100 mm max. opening

Weight : 12 kg
Bar code : 3700664802381
Catalogue P.253
THKS05 - High stability horizontal plate clamp 500 kg - 35 mm max. openingTHKS05
High stability horizontal plate clamp 500 kg – 35 mm max. opening

Weight : 3.1 kg
Bar code : 3700664803968
Catalogue P.253
THKS10 - High stability horizontal plate clamp 1000 kg - 60 mm max. openingTHKS10
High stability horizontal plate clamp 1000 kg – 60 mm max. opening

Weight : 6 kg
Bar code : 3700664802336
Catalogue P.253
THKS15 - High stability horizontal plate clamp 1500 kg - 60 mm max. openingTHKS15
High stability horizontal plate clamp 1500 kg – 60 mm max. opening

Weight : 6.5 kg
Bar code : 3700664802350
Catalogue P.253
THKS20 - High stability horizontal plate clamp 2000 kg - 60 mm max. openingTHKS20
High stability horizontal plate clamp 2000 kg – 60 mm max. opening

Weight : 7.5 kg
Bar code : 3700664802374
Catalogue P.253
THKS30 - High stability horizontal plate clamp 3000 kg - 60 mm max. openingTHKS30
High stability horizontal plate clamp 3000 kg – 60 mm max. opening

Weight : 10 kg
Bar code : 3700664802398
Catalogue P.253

  • Horizontal plate clamp
  • Load capacity: 1 to 3 metric tons (9 models available)
  • High stability lower base
  • Designed to be used in pairs or bundles with an appropriate sling
  • The use of a spreader bar is recommended to handle large sheet metal dimensions
  • Shackle and chain slings not included
  • Download the product specifications for further technical information
Model

THK10, THK15, THK20, THK30, THKS05, THKS10, THKS15, THKS20, THKS30
